R32 8kw Water Heater Heat Pump with Low Maintenance and English Operating Language

Name: R32 8kw Water Heater Heat Pump with Low Maintenance and English Operating Language
Brand: DUHM
Price: 1 USD

Wholesale R32 8kw Water Heater Heat Pump with Low Maintenance and English Operating Language from china suppliers

Place of Origin : China

Brand Name : DUHM

Model Number : WW08VM

Price : Negotiable

Certification : CE

MOQ : 2

Packaging Details : Polywood Pallet

Delivery Time : 25 working day

Payment Terms : T/T,L/C AT SIGHT

Supply Ability : 800 Sets/Day

After-sales Service Provided : Free spare parts

Warranty : 1 Year

Operating Language : English, German, French, Dutch, Spanish

Application : Hotel, Garage, Commercial, Household

Power Source : Electric

App-Controlled : Yes

logo/pattern : Silk screen printing

Type : Air Source Heat Pump, Monoblock

Installation : Freestanding

Storage / Tankless : Instant / Tankless

Use : Home

Product Name : R290 Monoblock with EVI Heat Pump

Heating Source : Air to Water Heat Pump

Function : Heating+Cooling+ DHW

Refrigerant : R32

Housing Material : Galvanized Steel with Powder coated

Heating Capacity(A7/6℃,W 30/35℃) (kW) : 6.8~17.8

Power Supply : 380-415V/3/50Hz/60Hz

ErP Rating (35℃/55℃) : A+++/A++

Compressor : DC Rotary

Contact Now

R32 8kw Water Heater Heat Pump with Low Maintenance and English Operating Language

Model	WW08VM	WW10VM	WW09VM	WW12VM	WW14VM	WW16VM	WW12VT	WW18VT	WW20VT	WW22VT
Heating Condition-Ambient Temp. (DB/WB): 7/6℃, Water Temp. (In/Out): 30/35℃
Heating Capacity Range (kW) )	3.46~7.87	5.51~10.12	3.89~9.69	5.91~12.31	6.85~14.28	7.96~16.32	5.88~12.33	8.95~18.36	9.95~20.40	10.35~22.44
Heating Power Input Range (kW)	0.69~1.78	1.08~2.24	0.74~2.10	1.16~2.72	1.35~3.21	1.58~3.71	1.16~2.74	1.76~4.08	1.96~4.58	2.06~5.04
COP (W/W)	4.41~4.95	4.51~5.06	4.60~5.20	4.53~5.08	4.44~5.05	4.40~5.02	4.49~5.07	4.50~5.06	4.45~5.06	4.45~5.02
Cooling Condition-Ambient Temp. (DB/WB): 35/24℃, Water Temp. (In/Out):12/7℃
Cooling Capacity Range (kW)	2.16~6.49	2.78~8.35	2.54~7.61	3.38~10.15	3.92~11.78	4.49~13.46	3.39~10.17	5.05~15.14	5.61~16.83	6.17~18.51
Cooling Power Input Range (kW)	0.76~2.68	0.97~3.41	0.89~3.10	1.21~4.26	1.37~4.75	1.59~5.47	1.20~4.23	1.82~6.20	2.04~6.95	2.22~7.49
EER (W/W)	2.42~2.81	2.45~2.85	2.45~2.85	2.38~2.78	2.48~2.85	2.46~2.82	2.40~2.82	2.44~2.76	2.42~2.75	2.47~2.77
Hot Water Condition -Ambient Temp. (DB/WB): 20/15℃,Water Temp. (In/Out): 15/55℃
Heating Capacity Range (kW)	2.93~8.81	3.77~11.33	3.44~10.33	4.59~13.78	5.33~15.96	6.09~18.27	4.60~13.81	6.85~20.56	7.61~22.85	8.37~25.13
Heating Power Input Range (kW)	0.59~2.09	0.76~2.68	0.69~2.43	0.92~3.29	1.09~3.97	1.25~4.51	0.93~3.36	1.40~5.10	1.54~5.50	1.71~6.09
COP (W/W)	4.20~4.95	4.22~4.95	4.25~4.98	4.18~4.94	4.02~4.88	4.05~4.85	4.11~4.90	4.03~4.88	4.15~4.92	4.12~4.88
ErP Rating (35℃/55℃)	A+++/A+	A+++/A++
Operating Ambient Temperature (℃)	-25~43
Max Outlet Water Temperature (℃)	60
Sound Pressure (1m) (dB(A))	51	52	52	53	54	54	53	56	56	56
Water System Data
Pipework Size (inch)	G1''
Water Flow (m³/h)	1.37	1.71	1.54	2.05	2.40	2.74	2.05	3.08	3.42	3.77
Water Pressure Drop (max.) (kPa)	15	20	20	20	25	30	20	35	40	40
Circulation Pump Water Head (m)	7.5	7.5	9.0	9.0	9.0	9.0	9.0	11.0	11.0	11.0
Electrical System Data
Power Supply	220-240V/1/50Hz						380-415V/3/50Hz
Max. Power Input (kW)	2.72	3.48	3.15	4.28	5.16	5.86	4.37	6.63	7.15	7.92
Max. Current Input (A)	12.43	15.95	14.41	19.57	23.62	26.83	7.43	11.28	12.16	13.46
Fuse Rating (A)	16	20	16	20	32	32	10	16	16	16
Key Components
Refrigerant R32 (kg)/CO2 Equivalent (Ton)	1.8/1.22	1.8/1.22	2.2/1.48	2.2/1.48	2.4/1.62	2.4/1.62	2.2/1.48	2.8/189	2.8/189	2.8/189
GWP	675
Compressor	DC Rotary Compressor
Fan Motor	DC Motor
Circulation Pump	1
Unit Dimension(LWH) (mm)	1155505855	1155505855	11754751050	11754751050	11754751050	11754751050	11754751050	11755051400	11755051400	11755051400
Shipping Dimension(LWH) (mm)	1190510980	1190510980	12055101185	12055101185	12055101185	12055101185	12055101185	12105401535	12105401535	12105401535
Net Weight /Gross Weight (kg)	115/125	115/125	135/145	135/145	140/150	145/155	135/145	165/180	165/180	165/180

R290/R32 Monoblock Heat Pump For House Heating ,

Cooling And Domestic Hot Water Supply.

Providing continuous spacing heating /cooling and hot water supply. The wotech R290 & R32 series multi-function heat pump has a range of benefits which sets it apart from the competition,including the unique designed fan housing. It significantly increased the airflow of the heat pump, making it more efficient, energy-saving, and environmentally friendly.

High Efficiency Level A+++/A++

Wotech R290 & R32 monoblock heat pump has passed the Erp A+++/A++ energy class test of Intertek

FAQ

1)Are you a manufacturer? Yes, we are a company and factory integrating R&D, production, and sales. At present, Wotech has three production bases in Shunde, Zhaoqing and Heyuan, Covering covering 100, 000 square meters. 2)Why should you select our heat pumps over those of other manufacturers? We have more than 19 years of experience in the heat pump field. Besides, we have a professional technical team, the industry's top heat pump laboratory, and automatic production lines. We can meet your diverse order requirements. 3)Do you offer OEM/ODM customised services? Yes. We are able to produce European-standard heat pumps under your brand according to your special needs. 4)Can you provide a sample service?

Yes, we are able to provide sample services.

5)How can we guarantee product quality? With many years of heat pump export experience, we set up a top international quality control system to achieve the belief of making the best quality heat pumps for global user
